C++20 Modules & Modern Build Systems: Replacing #include, CMake Integration, and 10x Faster Builds

// === math.ixx (or math.cppm) — Primary Module Interface Unit ===
export module math; // Declares this as the "math" module interface

// Private include (not exported — doesn't leak to importers):
#include <cmath>
#include <stdexcept>

// NOT exported — internal helper (invisible outside module):
double square_unchecked(double x) { return x * x; }

// EXPORTED — visible to importers:
export double square(double x) {
    return square_unchecked(x); // Can use non-exported helpers internally
}

export double sqrt_safe(double x) {
    if (x < 0) throw std::domain_error("sqrt of negative number");
    return std::sqrt(x);
}

export constexpr double PI = 3.14159265358979323846;

// Export a group without touching each declaration:
export {
    double cube(double x) { return x * x * x; }
    double hypot(double a, double b) { return sqrt_safe(square(a) + square(b)); }
}

// === main.cpp — Importer ===
import math; // Import compiled binary metadata — fast!

int main() {
    double r = square(5.0);   // 25.0
    double h = hypot(3.0, 4.0); // 5.0
    // square_unchecked(5.0); // ERROR: not exported, not visible
    return 0;
}

// === geometry:shapes.ixx — Module Partition ===
export module geometry:shapes;  // Partition "shapes" of module "geometry"

export struct Circle  { double radius; };
export struct Rectangle { double w, h; };
export struct Triangle { double a, b, c; };

// === geometry:algorithms.ixx — Another Partition ===
export module geometry:algorithms;
import :shapes;  // Import the shapes partition (within same module)

export double area(const Circle& c) { return 3.14159 * c.radius * c.radius; }
export double area(const Rectangle& r) { return r.w * r.h; }

// === geometry.ixx — Primary Interface (assembles partitions) ===
export module geometry;
export import :shapes;      // Re-export shapes partition
export import :algorithms;  // Re-export algorithms partition

// The importer sees everything from both partitions:
// import geometry; → gets Circle, Rectangle, Triangle, area()

// === geometry-impl.cpp — Module Implementation Unit ===
module geometry;  // Belongs to geometry module (no "export")
// Not an interface — cannot be imported directly
// Provides implementations that are NOT in the interface
// Useful for separating declarations from implementations without headers

// Traditional — slow header includes:
#include <iostream>
#include <vector>
#include <string>
#include <algorithm>
#include <ranges>
// Re-parses 500,000+ lines on every file

// C++23 — fast module import:
import std;         // Import entire C++ standard library as one module
import std.compat;  // Also imports C compatibility (printf, etc.)

// Now immediately available:
std::println("Hello, modules!");
std::vector<int> v = {3, 1, 4, 1, 5};
std::ranges::sort(v);

// Build time improvement: #include <vector> alone → 50ms parse
// import std; → ~5ms (compiled once, cached binary metadata)

// Import a legacy header as a header unit:
import <vector>;      // Imports <vector> as a header unit
import "mylib.h";     // Import a project header as a header unit

// Header units:
// - Compile the header once and cache the result
// - Macros still leak (unlike proper modules)
// - Easy migration: change #include to import, get build time benefits
// - Eventually migrate to proper module when ready

// Migration path:
// Phase 1: Change #include <vector> → import <vector>; (2 min, 50% faster build)
// Phase 2: Create module:shapes (replaces shapes.h/shapes.cpp)
// Phase 3: import std; (replace all STL includes)

cmake_minimum_required(VERSION 3.28)
project(MyProject CXX)

set(CMAKE_CXX_STANDARD 23)
set(CMAKE_CXX_STANDARD_REQUIRED ON)

# Enable experimental modules support (required for some generators):
set(CMAKE_EXPERIMENTAL_CXX_MODULE_CMAKE_API "3c375311-a3c9-4396-a187-3227ef642046")

# Main executable:
add_executable(MyApp main.cpp)

# Add module interface units:
target_sources(MyApp
    PUBLIC
    FILE_SET CXX_MODULES  # Tell CMake these are module files
    FILES
        math.ixx
        geometry:shapes.ixx
        geometry:algorithms.ixx
        geometry.ixx
)

# Or use a library:
add_library(MathLib)
target_sources(MathLib
    PUBLIC
    FILE_SET CXX_MODULES FILES math.ixx
)
target_link_libraries(MyApp PRIVATE MathLib)

# Use import std (CMake 3.30+):
# target_compile_features(MyApp PRIVATE cxx_std_23)

Project → Properties → C/C++ → Language → C++ Language Standard: C++23
Rename math.h + math.cpp to math.ixx (single file)

clang++ -std=c++23 -fmodules --precompile math.ixx -o math.pcm
clang++ -std=c++23 -fmodules -fmodule-file=math=math.pcm main.cpp

Project: 100 TUs, each including <string>, <vector>, <map>, <algorithm>

Without modules (headers only):
  Cold build:    185 seconds
  Incremental:   12 seconds (one file changed)

With import std; (C++23):
  Cold build:    22 seconds  (8.4× faster)
  Incremental:   2 seconds   (6× faster)

With full modules:
  Cold build:    15 seconds  (12× faster)
  Incremental:   0.4 seconds (30× faster!)

Data from MSVC team benchmarks (2024, 24-core build machine)
