Read-heavy (>80% reads)   → Replication (add read replicas)
Write-heavy (>40% writes) → Sharding (split writes across nodes)
Both heavy                → Shard + replicate each shard
Dataset > single disk     → Sharding is required regardless

import { Pool } from 'pg';

const primary = new Pool({
  host: process.env.DB_PRIMARY_HOST,
  database: 'appdb',
  max: 20,
});

const replicas = [
  new Pool({ host: process.env.DB_REPLICA_1_HOST, database: 'appdb', max: 20 }),
  new Pool({ host: process.env.DB_REPLICA_2_HOST, database: 'appdb', max: 20 }),
];

let replicaIndex = 0;

function getReadPool(): Pool {
  // Round-robin across replicas
  const pool = replicas[replicaIndex % replicas.length];
  replicaIndex++;
  return pool;
}

export const db = {
  query: (sql: string, params?: unknown[]) => primary.query(sql, params),
  queryRead: (sql: string, params?: unknown[]) => getReadPool().query(sql, params),
};

// Usage
const users = await db.queryRead('SELECT * FROM users WHERE active = true');
await db.query('INSERT INTO users (email) VALUES ($1)', [email]);

User writes profile update → primary confirms
User immediately reads profile → replica returns stale data
User sees their own update vanish → rage-quit

// 1. Always read your own writes from primary
async function getUserProfile(userId: string, justUpdated = false): Promise<User> {
  const pool = justUpdated ? primary : getReadPool();
  const result = await pool.query('SELECT * FROM users WHERE id = $1', [userId]);
  return result.rows[0];
}

// 2. Sticky sessions: send the same user to the same replica
function getReplicaForUser(userId: string): Pool {
  const index = hashUserId(userId) % replicas.length;
  return replicas[index];
}

// 3. Read after write with lag check
async function waitForReplication(expectedVersion: number): Promise<void> {
  const maxWait = 2000; // ms
  const start = Date.now();

  while (Date.now() - start < maxWait) {
    const result = await getReadPool().query(
      'SELECT pg_last_xact_replay_timestamp() as lag'
    );
    if (result.rows[0].version >= expectedVersion) return;
    await sleep(50);
  }
  // Fall back to primary read
}

Without sharding:
┌─────────────────────────────┐
│  Single DB (1B rows)        │
│  Writes: 50k/s → bottleneck │
└─────────────────────────────┘

With 4 shards:
┌──────────────┐  ┌──────────────┐
│  Shard 0     │  │  Shard 1     │
│  250M rows   │  │  250M rows   │
│  12.5k/s     │  │  12.5k/s     │
└──────────────┘  └──────────────┘
┌──────────────┐  ┌──────────────┐
│  Shard 2     │  │  Shard 3     │
│  250M rows   │  │  250M rows   │
│  12.5k/s     │  │  12.5k/s     │
└──────────────┘  └──────────────┘

User IDs 1–25M        → Shard 0
User IDs 25M–50M      → Shard 1
User IDs 50M–75M      → Shard 2
User IDs 75M–100M     → Shard 3

class RangeShardRouter {
  private ranges = [
    { min: 0,        max: 25_000_000, shard: 0 },
    { min: 25000001, max: 50_000_000, shard: 1 },
    { min: 50000001, max: 75_000_000, shard: 2 },
    { min: 75000001, max: 100_000_000, shard: 3 },
  ];

  getShard(userId: number): number {
    const range = this.ranges.find(r => userId >= r.min && userId <= r.max);
    if (!range) throw new Error(`No shard for userId ${userId}`);
    return range.shard;
  }
}

class HashShardRouter {
  constructor(private shardCount: number) {}

  getShard(shardKey: string): number {
    const hash = this.fnv1a(shardKey);
    return hash % this.shardCount;
  }

  private fnv1a(str: string): number {
    let hash = 2166136261;
    for (const char of str) {
      hash ^= char.charCodeAt(0);
      hash = (hash * 16777619) >>> 0; // unsigned 32-bit
    }
    return hash;
  }
}

// Usage
const router = new HashShardRouter(4);
const shard = router.getShard(userId); // deterministic, uniform

          "user:abc" (hash: 120)
               ↓
    ──────────●──────────
  /    Node A           \
 /    (tokens: 0,90)     \
●                         ●
Node D                   Node B
(tokens: 270,360)        (tokens: 180,270)
 \                       /
  \   Node C            /
   ──────────●──────────
         (tokens: 90,180)

"user:abc" hash 120 → falls between 90 and 180 → routes to Node C

class ConsistentHashRouter {
  private ring = new Map<number, string>(); // position → nodeId
  private sortedPositions: number[] = [];
  private virtualNodes = 150; // virtual nodes per physical node

  addNode(nodeId: string): void {
    for (let i = 0; i < this.virtualNodes; i++) {
      const pos = this.hash(`${nodeId}:vnode:${i}`);
      this.ring.set(pos, nodeId);
    }
    this.sortedPositions = [...this.ring.keys()].sort((a, b) => a - b);
  }

  removeNode(nodeId: string): void {
    for (let i = 0; i < this.virtualNodes; i++) {
      const pos = this.hash(`${nodeId}:vnode:${i}`);
      this.ring.delete(pos);
    }
    this.sortedPositions = [...this.ring.keys()].sort((a, b) => a - b);
  }

  getNode(key: string): string {
    const keyHash = this.hash(key);
    // Find the first position >= keyHash (wrap around)
    const pos = this.sortedPositions.find(p => p >= keyHash)
      ?? this.sortedPositions[0];
    return this.ring.get(pos)!;
  }

  private hash(input: string): number {
    // Use a real hash function (crypto.createHash) in production
    let h = 5381;
    for (const c of input) h = ((h << 5) + h) ^ c.charCodeAt(0);
    return Math.abs(h) % 360_000;
  }
}

// Bad: tenant's orders split across shards by order_id
// A tenant query must scatter to all shards
router.getShard(orderId); // ❌

// Good: tenant's orders co-located by tenant_id
// All of tenant's data on one shard
router.getShard(tenantId); // ✅

class ShardedOrderService {
  constructor(
    private pools: Pool[],
    private router: HashShardRouter
  ) {}

  // Simple: single shard lookup by shard key
  async getOrder(orderId: string, userId: string): Promise<Order> {
    const shard = this.router.getShard(userId);
    const result = await this.pools[shard].query(
      'SELECT * FROM orders WHERE id = $1 AND user_id = $2',
      [orderId, userId]
    );
    return result.rows[0];
  }

  // Hard: aggregate across all shards (scatter-gather)
  async getRevenueLastHour(): Promise<number> {
    const queries = this.pools.map(pool =>
      pool.query(
        "SELECT SUM(amount) as revenue FROM orders WHERE created_at > NOW() - INTERVAL '1 hour'"
      )
    );
    const results = await Promise.all(queries);
    return results.reduce((total, r) => total + Number(r.rows[0].revenue), 0);
  }

  // Avoid: JOIN across shards — fetch then join in application
  async getUsersWithOrders(userIds: string[]): Promise<UserWithOrders[]> {
    // Group userIds by shard
    const shardBuckets = new Map<number, string[]>();
    for (const uid of userIds) {
      const shard = this.router.getShard(uid);
      if (!shardBuckets.has(shard)) shardBuckets.set(shard, []);
      shardBuckets.get(shard)!.push(uid);
    }

    // Parallel queries per shard
    const shardResults = await Promise.all(
      [...shardBuckets.entries()].map(([shard, ids]) =>
        this.pools[shard].query(
          'SELECT u.*, json_agg(o.*) as orders FROM users u LEFT JOIN orders o ON o.user_id = u.id WHERE u.id = ANY($1) GROUP BY u.id',
          [ids]
        )
      )
    );

    return shardResults.flatMap(r => r.rows);
  }
}

Strategy: Double-write during migration

Phase 1: Write to old shards + new shards simultaneously
Phase 2: Backfill historical data to new shards
Phase 3: Verify new shards are complete
Phase 4: Switch reads to new shards
Phase 5: Stop writes to old shards
Phase 6: Decommission old shards

class MigrationShardRouter {
  private phase: 'old' | 'double-write' | 'new' = 'old';

  getShard(key: string): number {
    if (this.phase === 'old') return this.oldRouter.getShard(key);
    if (this.phase === 'new') return this.newRouter.getShard(key);
    return this.oldRouter.getShard(key); // reads still from old during double-write
  }

  async write(key: string, sql: string, params: unknown[]): Promise<void> {
    if (this.phase === 'double-write') {
      // Write to both, don't fail on new shard errors
      await Promise.allSettled([
        this.oldPools[this.oldRouter.getShard(key)].query(sql, params),
        this.newPools[this.newRouter.getShard(key)].query(sql, params),
      ]);
    } else {
      const shard = this.getShard(key);
      const pool = this.phase === 'old' ? this.oldPools[shard] : this.newPools[shard];
      await pool.query(sql, params);
    }
  }
}

                    Application
                        │
              ┌─────────┼─────────┐
              â–¼         â–¼         â–¼
          Shard 0    Shard 1    Shard 2
          Primary    Primary    Primary
            │           │          │
         Replica     Replica    Replica
         Replica     Replica    Replica

interface ShardMetrics {
  shardId: number;
  replicationLagMs: number;
  queryLatencyP99Ms: number;
  connectionPoolUtilization: number; // 0-1
  diskUsagePercent: number;
}

async function collectShardMetrics(pools: Pool[]): Promise<ShardMetrics[]> {
  return Promise.all(
    pools.map(async (pool, shardId) => {
      const [lag, disk] = await Promise.all([
        pool.query(`
          SELECT EXTRACT(EPOCH FROM (NOW() - pg_last_xact_replay_timestamp())) * 1000 AS lag_ms
        `),
        pool.query(`
          SELECT pg_database_size(current_database()) / 1073741824.0 AS size_gb
        `),
      ]);
      return {
        shardId,
        replicationLagMs: lag.rows[0].lag_ms ?? 0,
        queryLatencyP99Ms: 0, // pulled from APM
        connectionPoolUtilization: pool.totalCount / pool.options.max!,
        diskUsagePercent: (lag.rows[0].size_gb / 500) * 100, // 500GB max per shard
      };
    })
  );
}
